Linear Actuators Manufacturers in California

Our linear actuator range delivers axial forces from 1,000N (220 LBS) up to 77,500N (7,000 LBS), providing scalable options for light manipulation tasks through to heavy-duty subsea machinery. The 60,000N Force model reaches 50,000N, suitable for pipeline control and large valve actuation in offshore environments.

The actuators are built from Stainless Steel 316 (SST 316) or Titanium, both of which offer excellent corrosion resistance in marine and saltwater environments. Titanium is recommended for the most aggressive deep-sea conditions where weight reduction and maximum corrosion resistance are critical requirements.

The Self-Compensated Linear Actuator supports RS422 (RS485 full duplex) and RS232 serial communication at 19200 baud. The integrated control electronics allow standalone position control without external drivers. The Trunion 1000N and 60,000N Force models use an external rotary resolver on the motor shaft for position feedback.

Yes. The Self-Compensated model features a 30-bit absolute multi-turn encoder mounted on the output shaft, retaining position data between power cycles with 14-bit resolution per turn. The Trunion 1000N and 60,000N Force models include a rotary resolver on the motor shaft for precise real-time position feedback.

Power supply options vary by model. The Self-Compensated actuator operates on 24 VDC. The Trunion 1000N supports 24 VDC, 48 VDC, and 230 VDC, offering flexibility for different ROV and subsea system power architectures. The 60,000N Force model operates on 230 VDC to support its high-force brushless motor.

The Trunion 1000N and 60,000N Force models use Seacon underwater connectors, widely recognized for reliable subsea electrical connectivity. The Self-Compensated model is equipped with an MCBH8M SubConn 8-pin underwater connector, supplied with a 12-inch MCIL8F whip for straightforward integration into ROV and subsea control systems.
