Stainless Steel Actuators in California

The actuators are constructed from Stainless Steel 316 (SST 316) or Titanium. Both materials offer superior corrosion resistance in marine and subsea environments. Titanium is recommended for the most aggressive deep-sea applications where weight reduction and maximum corrosion resistance are critical priorities.

Depending on the model, position feedback is provided either via a rotary resolver on the motor shaft or an integrated 30-bit absolute multi-turn encoder mounted on the output shaft. The absolute encoder models retain exact position information between power cycles, eliminating the need for re-homing after power interruptions.

The self-compensated models support RS422 (RS485 duplex on 4 wires) and RS232 serial communication at 19200 baud (8, N, 1). All communication parameters and virtual limit switch settings are stored in internal EEPROM. A Windows software utility is also provided to simplify setup and configuration.

Linear actuator force output ranges from 1,000 N (220 LBS) on the entry self-compensated model up to 77,500 N (approximately 17,400 LBS) on the Trunion series, with the 60,000 N Force model delivering 50,000 N. This wide range allows selection based on the specific load requirements of the subsea application.

Yes. All models are specifically designed for ROV integration, subsea valve actuation, and offshore oil and gas equipment. Their compact cylindrical housings (2.25" OD on self-compensated models), Seacon or Subcon underwater connectors, and depth-rated construction make them directly compatible with standard ROV and subsea tooling architectures.

Yes. NV Mechanics Design offers custom configuration inquiries for force output, stroke length, power supply voltage (24 VDC, 48 VDC, or 230 VDC depending on model), and connector type. PDF drawings and STEP files are available for all models to support mechanical integration, and the manufacturer provides direct technical support for custom requirements.
