Underwater Proximity Sensor

The sensor is constructed from SST 316 (stainless steel), Inconel, and Titanium. These materials are selected for their superior corrosion resistance, mechanical strength, and durability in harsh saltwater and high-pressure subsea environments.

The PSW23-20000-0 provides both Normally Open (NO) and Normally Closed (NC) signal outputs via its MCBH8M connector. Pin 1 to Pin 2 delivers the Normally Open signal, while Pin 2 to Pin 3 delivers the Normally Closed signal, offering flexible integration options.

No external power supply is required for the Proximity Sensor PSW23-20000-0. It is a passive device, making it ideal for simplified subsea installations where minimizing power requirements and system complexity is essential for reliable long-term operation.

The sensor ships with a magnet and a 2-foot whip cable fitted with a mating connector. These included accessories facilitate straightforward installation and integration into existing subsea systems without requiring additional hardware procurement.

The PSW23-20000-0 uses an MCBH8M wet-mate connector, a widely adopted standard in subsea instrumentation. This connector type ensures a reliable, waterproof electrical interface suitable for deep-water deployment and integration with ROVs and other underwater equipment.

The sensor is designed for subsea ROV trenchers, subsea drills, underwater equipment position detection, and signal detection in deep-sea environments. It is also used in offshore oil and gas subsea systems where precise, reliable proximity sensing at extreme depths is required.
