Stainless Steel Actuator Options Available in Maine

The actuators are constructed from either Stainless Steel 316 (SST 316) or Titanium, depending on the model and application requirements. Both materials provide excellent corrosion resistance in saltwater and marine environments. SST 316 is standard; Titanium is available for weight-critical or highly corrosive deployments.

The self-compensated linear and rotary actuators support RS422 (wired as RS485 duplex on 4 wires) and RS232 serial communication at 19200 baud, 8, N, 1. All configurable parameters — including limit switches and broadcast frequency — are stored in internal EEPROM and can be adjusted via the included Windows utility software.

Yes. The self-compensated models feature a 30-bit absolute multi-turn encoder mounted on the output shaft. This encoder retains full position data between power cycles without requiring a homing routine, which is critical for subsea systems where power interruptions can occur during long deployments.

Force output varies by model. The Linear Underwater Actuator Trunion 1000N delivers 1,000 N to 77,500 N (220 to 7,000 lbs) of axial force, the Linear Actuator 60,000 N Force provides up to 50,000 N, and the Self-Compensated Linear Actuator delivers up to 1,500 N (330 lbs). Select based on load demands and depth requirements.

High-force linear actuators (1000N Trunion and 60,000N models) use Seacon underwater connectors, which are industry-standard for subsea applications. The self-compensated linear and rotary actuators use MCBH8M SubConn 8-pin underwater connectors, with a 12" MCIL8F whip cable included on the linear self-compensated variant for immediate integration.

Yes. All models in this lineup are specifically designed for subsea environments and are actively used in remotely operated vehicles (ROVs), subsea valve actuation, offshore oil and gas pipeline control, marine research platforms, and underwater robotic systems. The brushless motor design ensures long service life in these demanding applications.
