Electric and Pneumatic Valve Actuators Guide

The self-compensated linear and rotary actuators support RS422 (RS485 duplex on 4 wires) and RS232 serial communication at 19,200 baud (8, N, 1). Configurable parameters, including status broadcast frequency and virtual limit switches, are stored in internal EEPROM for persistent, power-cycle-safe operation.

The self-compensated models feature an integrated 30-bit absolute multi-turn encoder mounted on the output shaft, providing 14-bit single-turn resolution (16,383 counts/turn) with position retained between power cycles. The 6,000m linear actuators use an external rotary resolver on the motor shaft for precise position feedback.

The 6,000m-rated linear actuators are available in Stainless Steel 316 (SST 316) or Titanium, both offering superior corrosion resistance for offshore and deep-sea marine environments. The self-compensated models use sealed housings with subcon MCBH underwater connectors rated for deep submersion.

The self-compensated linear and rotary actuators operate on 24 VDC. The Trunion 1000N linear actuator accepts 24 VDC, 48 VDC, or 230 VDC, while the 60,000N linear actuator operates on 230 VDC. Selecting the correct voltage is critical for integration with ROV or subsea control system power buses.

The self-compensated linear actuator delivers 220 to 330 LBS (1,000–1,500N). The Trunion 1000N scales from 220 LBS (1,000N) up to 7,000 LBS (77,500N) for heavy-duty applications. The 60,000N model provides up to 50,000N, making it suitable for high-force subsea valve actuation and industrial underwater machinery.

Yes. All models are designed for subsea valve actuation, pipeline control, and ROV integration in offshore oil and gas environments. The 6,000m depth rating, corrosion-resistant SST 316 or titanium construction, and Seacon underwater connectors make them well-suited for demanding offshore infrastructure and deepwater operations.
